Introducing our innovative Dual-Head Stone Engraving Machine—a versatile solution engineered to master both flat and complex curved stone carving with unparalleled precision.
Product Model :
JZY3025FB-2DCertification :
CE, ISOSpecifications :
4300*2300*2300Origin :
QuanzhouPort :
XiamenSamples Available :
NoAfter-Sales Service :
ProvideWarranty Period :
1 Year
This machine combines two specialized heads: a standard flat-carving head, optimized for crisp, detailed flat surface engraving on stone slabs, and a 180° swivel engraving head, designed to tackle challenging curved stone panels and decorative stone caps with large-angle carving requirements.
Whether you’re crafting smooth flat patterns, intricate logos on straight surfaces, or bold, multi-angle designs on curved edges or ornate stone caps, this dual-head system eliminates the need for multiple machines, streamlining your workflow while ensuring flawless results on diverse stone materials.
1).Dual-Head Versatility: Equipped with a standard flat-carving head for precise 2D patterns, text, and designs on flat stone surfaces, paired with a 180° swivel head that rotates freely to handle large-angle carving on curved, rounded, or irregular stone shapes.
2).180° Swivel Head Precision: The swivel engraving head features smooth, adjustable rotation, allowing seamless transitions between angles to tackle curved panels and decorative caps without compromising detail or accuracy.
3).Stone-Optimized Performance: Both heads are fine-tuned for stone materials, with adjustable speed, pressure, and depth settings to prevent chipping—ensuring clean, polished finishes on both hard granite and soft limestone stone varieties.
4).Integrated Smart Control: Compatible with intuitive design software, enabling easy import of 2D/3D patterns, real-time angle previews for the swivel head, and synchronized operation between both heads for efficient multi-tasking.
5).Robust Stability: Built with a heavy-duty frame, anti-vibration guides, and heat-resistant components to maintain stability during high-intensity carving, even when handling large or heavy stone pieces.
Technical Parameters
| Product Number | 3015FB-2D |
| Platform Dimensions | 3000*1500mm |
| Working Size | 1400*1400*2mm |
| Feed Height | ≤600mm |
| Air Speed | 15m/min |
| Processing Speed | 12m/min |
| Spindle Power | 5.5-7.5kw/Motorized spindle |
| Spindle Speed | 6000-24000 rpm/min |
| Motor | AC digital servo motor |
| Reducer | JZ8098 |
| Operating Voltage | AC220V/50Hz/AC380V/50Hz |
| Engraving Tool | Φ6/8/10/12/14/16mm |
| File Format | G code/HPGL |
| Positioning Accuracy | ±0.02mm |
| Repeatability | ±0.01mm |
| Control System | Taiwan LNC |
| Machine Dimensions | 4300*3000*2300mm |
| Weight | 3200kg |
Applications
1).Flat Stone Decor: Engraving logos, text, or geometric patterns on flat stone slabs for countertops, wall panels, or floor tiles in residential and commercial spaces.
2).Curved Architectural Elements: Carving intricate designs on curved stone panels used in building facades, arches, or column wraps, adding depth to architectural details.
3).Ornate Stone Caps & Finials: Creating detailed motifs on decorative stone caps for fences, pillars, or garden structures, where large-angle carving is essential for symmetry and flair.
4).Custom Stone Art: Producing mixed-surface artworks—combining flat engravings and curved details on sculptures, memorial stones, or outdoor decor pieces.
Company Profile
Quanzhou Jinzuan Technology Co., Ltd.
Quanzhou Jinzuan Technology Co., Ltd. is located in Shuitou Industrial Avenue with convenient transportation. It is a company integrating R & D, manufacturing, sales and technical services, specializing in manufacturing a series of intelligent CNC equipment, such as stone carving machine, four axis and five axis engraving machine, CNC machining center and three-dimensional engraving machine. With the help of perfect product production supply chain and strong technical service team, the company focuses more on the research and development of digital intelligent engraving technology, boosting the upgrading of engraving machine performance and function.
Now it has become a domestic CNC engraving machine production and export volume of enterprises, and one-time through ISO9001,CE certification, ROHS certification and BV certification, the products are sold all over the country, and exported to Europe, America, Southeast Asia, the Middle East and more than 60 countries and regions.
Certifications
Exhibitions
Our Service
Pre-sale: consulting support
according to customer's requirements to install the machine
visit the factory
After-sale: machine installation and usage guidance
one-year warranty period
FAQ
1.What will the payment process be?
TT : 30% as deposit, 70% before shipping.
2.How many days will take shipping?
About 30 days for production time. Shipping date from Xiamen port to your port need to be check.
3.Who will provide the technical support to installing the device?
1).Our engineer could train you for install and software using and design in our factory for free. One week is enough. Our factory is at Shuitou town, Fujian province. The biggest stone manufacture area in China. Maybe also the biggest importer &exporter of marble all over the world.
2).Our engineer could service you 24 hours online by skype, whatsapp, wechat, facebook message or by cellphone.
3).English manual for machine using and maintaining can be sent.
4).Video for installation and machine using and maintaining can be sent.
